2- HI 28" (700 MM) HV SMS/MEER CANTILEVER, MOD# CL 700 V, 6X6 & 4X4, MFG 2013, ROUGHING MILL BAR STANDS
 "20090400100 2- HI 28\" (700 MM) HV SMS/MEER CANTILEVER, MOD CL 700 V, 6X6 & 4X4, MFG 2013, ROUGHING MILL BAR STANDS")
2- HI 28" (700 MM) HV SMS/MEER CANTILEVER, MOD# CL 700 V, 6X6 & 4X4, MFG 2013, ROUGHING MILL BAR STANDS
MANUFACTURER: SMS / MEER
MODEL: CL 700 V
AGE: 2013
TYPE: 85 MPS - CANTILEVER
CAPACITY: 6 1/4" (160 MM) SQUARE BILLET - WEIGHT 2 TON X 36' LONG BILLETS
CAPACITY: 70 TO 80 TPH
STAND 1: VERTICAL STAND 27.6" (700 MM) BOTTOM DRIVEN
STAND 2: HORIZONTAL STAND 28" (700 MM)
ROLL DIAMETER: 24" TO 28" (600 MM - 680 MM)
ROLL FACE: 12" (300 MM)
ROLL CENTERLINE DISTANCE GAP: 15" (377 MM) MIN TO 20" (512 MM) MAX
ROLL CENTERLINES: 22" (590 MM) MIN 28" (711 MM) MAX
DIRECTION OF TRAVEL: LEFT TO RIGHT
EACH STAND IS DRIVEN BY ITS OWN AC MOTOR
400 KW 743 RPM 480 VOLT AC INVERTER MOTOR (Estimated: 7,937 LBS (3600 KG)
CARTRIDGE WEIGHT: 39,000 LBS (690 KG)
130 BAR HYDRAULIC PRESSURE
PREVIOUS USE: STAND ONE ON A 350,000 TPY ROD MILL REDUCED 6 1/4" SQUARE BILLETS
INVENTORY#: 200904-001-00
| INVENTORY ID | 20090400100 |
| TITLE | 2- HI 28" (700 MM) HV SMS/MEER CANTILEVER, MOD# CL 700 V, 6X6 & 4X4, MFG 2013, ROUGHING MILL BAR STANDS |
| WORK ROLL DIA. | 24" TO 28" |
| WORK ROLL FACE | 12" |
| MANUFACTURER OF EQUIPMENT | SMS / MEER |
| YEAR OF MANUFACTURE | 2013 |
| PREVIOUS USE | STAND ONE ON A 350,000 TPY ROD MILL REDUCED 6 1/4" SQUARE BILLETS |
| WEIGHT | CARTRIDGE WEIGHT: 39,000 LBS |
| MOTOR RPM | 743 RPM |
| MOTOR VOLTS | 480 VOLT |
| AC OR DC | AC INVERTER MOTOR |
