36" 6,000 LBS LITTELL ADV. 6000 PAYOFF REEL

36", 6,000 LBS (915MM) LITTELL NO. ADV. 6000 PAYOFF REEL

MANUFACTURER: LITTELL

AGE: 1990's

MODEL #: ADV. 6000

SERIAL #: 92439-96

GENERAL SPECIFICATIONS:

CAPACITY: 6,000 LBS

COIL WIDTH MAX: 30" (760 MM)

COIL ID: 15" - 20" (380 MM - 500 MM)

COIL O.D.: 60" (1525 MM)

MANDREL: FOUR SEGMENTS, MANUAL EXPANSION

MOTOR DATA: 2 HP, 1170 RPM, 230/460 V

DIMENSIONS: 93" LENGTH X 36" WIDTH X 54" HEIGHT (2360MM LENGTH X 915 MM WIDTH X 1370 MM HEIGHT)

WEIGHT: 1950 LBS (885 KG)

FEATURES: ALREADY DISMANTLED

INVENTORY #: 200645-000-00

INVENTORY ID	20064500000
TITLE	36" 6,000 LBS LITTELL ADV. 6000 PAYOFF REEL
COIL O.D.	60
MANUFACTURER OF EQUIPMENT	LITTELL
YEAR OF MANUFACTURE	1990'S
MODEL NO	ADV. 6000
SERIAL NO	92439-96
MANDREL FACE	36
MANDREL (SINGLE, DOUBLE)	FOUR SEGMENTS, MANUAL EXPANSION
DRIVE MOTOR HP	2
MOTOR RPM	1170
MOTOR VOLTS	230/460
OVERALL LENGTH	93
OVERALL WIDTH	36
OVERALL HEIGHT	54
TOTAL WEIGHT	1950
FEATURES 1	ALREADY DISMANTLED
