24" (610 MM) WIDE WATERBURY FARREL SINGLE STAND 4 HIGH COLD MILL (NCO)
 "20008400000 24\" (610 MM) WIDE WATERBURY FARREL SINGLE STAND 4 HIGH COLD MILL (NCO)")
 "20008400000 24\" (610 MM) WIDE WATERBURY FARREL SINGLE STAND 4 HIGH COLD MILL (NCO)")
 "20008400000 24\" (610 MM) WIDE WATERBURY FARREL SINGLE STAND 4 HIGH COLD MILL (NCO)")
| INVENTORY ID | 20008400000 |
| TITLE | 24" (610 MM) WIDE WATERBURY FARREL SINGLE STAND 4 HIGH COLD MILL (NCO) |
| MILL WIDTH | 24 |
| NUMBER STANDS | 1 |
| MANUFACTURER OF EQUIPMENT | WATERBURY FARREL |
| YEAR OF MANUFACTURE | 1967 |
| MATERIAL ROLLED | STEEL |
| NUMBER STANDS | 1 |
| REVERS/NONREV | NON REVERSING |
| ROLL CONFIGURATION (2 HI, 4 HI, 6 HI) | 4 HIGH |
| STARTING COIL WIDTH | 19 |
| STARTING COIL GAUGE MAX | 0.200 |
| STARTING COIL O D | 47 |
| STARTING COIL I D | 16 |
| STARTING COIL WEIGHT | 5700 |
| FINISHED COIL GAUGE MAX | 0.035 |
| FINISHED COIL I D | 20 |
| LINE SPEED | 300 |
| DIRECTION OF TRAVEL (VIEWED FROM OPERATOR SIDE) | RIGHT TO LEFT |
| HSG CLOSED-OPEN TOP | CLOSED TOP |
| HSG CONSTR (FAB OR CAST) | CAST |
| WORK ROLL DIA STAND 1 | 11 |
| WR FACE | 24 |
| WR BRG | ROLLER |
| BU ROLL DIA | 25 |
| BU ROLL FACE | 24 |
| BU ROLL BRG | ROLLER |
| MOTOR HP | 500 |
| NUMBER OF MOTORS | 1 |
| MOTOR RPM | 850 |
| SCREWDOWN TYPE | ELECTRO MECHANICAL |
| COMBINATION PIN RED RATIO (:1) | 12 |
| PAYOFF COIL CAR | 2 |
| PAYOFF REEL STYLE | EXPANDING MANDREL TYPE |
| PAYOFF MANDREL DIA | 16 |
| PAYOFF REEL MOTOR HP | 100 |
| EXIT REEL STYLE | EXPANDING MANDREL |
| EXIT REEL MANDREL DIA | 20 |
| EXIT COIL CAR | LIFT TRANSFER TYPE (PIT) |
| OVERALL LENGTH | 32 |
