DANIELI 17.36 SQ IN (11200 SQ MM) CVSB 125 CRANK ARM SHEAR
MANUFACTURER: DANIELI
AGE: 2005
MODEL: CVSB 125
GENERAL SPECIFICATIONS
CAPACITY: 17.36 SQ IN (11200 SQ MM)
CUTTING FORCE: 140 UST (1250 Kn)
TYPE OF MATERIAL: STEEL
MATERIAL SHAPE: BAR
TYPE: PARALLEL CRANK ARM
NUMBER OF BLADES: 2
KNIFE BLADE: 9" (228.6 MM)
MATERIAL SPEED: 195 TO 465 FPM (.99 TO 2.38 MPS)
DRIVE: DIRECT DRIVE - START STOP
MOTOR:
o SIEMENS (subject to availability)
o 750 HP
o 460V (547 Kw)
DIRECTION OF TRAVEL: RIGHT TO LEFT
NUMBER OF BLADES: 2
KNIFE BLADE: 9" LONG (230MM)
MAX SHEAR SPEED: 465 FPM (2.38 MPS)
PREVIOUS USE: CROP SHEAR
FEATURES:
o ALREADY DISMANTLED
o CENTRAL LUBRICATION SYSTEM (317 GALLON - 1200 L)
o SINAMICS DRIVE (AVAILABILITY TO BE DETERMINED)
o SPARE MOTOR MAY BE AVAILABLE (ITEM: 122862-000-00)
| INVENTORY ID | 20086400000 |
| TITLE | DANIELI 17.36 SQ INCHES CRANK ARM SHEAR |
| MANUFACTURER OF EQUIPMENT | DANIELI |
