STRAIGHTEN AND SHEAR LINE FOR ANGLES, CHANNELS AND FLATS CONSISTS OF
MANUFACTURER: SIMAC
YEAR: 1997
5 OVER 5 MULTISTAND SHAPE STRAIGHTENER
15" DIAMETER ROLLS X 22" FACE
175 HP
300 TO 500 FPM
5 BARS AT A TIME
225 TON FLYING SHEAR
23" BLADE
2 X 400 HP MOTORS
STACKER 16" BUNDLES SIZES UP TO 40 FT LONG
ORGAPACK 2 HEAD ADJUSTABLE BANDER
COMPLETE WITH ALL NECESSARY TABLES
PRODUCTS:
FLATS: 1” TO 4”
ANGLES: ¾” TO 2-1/2”
CHANNELS: 1” TO 4“
ROUNDS: 0.5” TO 1.25” (12MM TO 32MM)
STRAIGHTENER: 10 ROLL MULTI-STRAND (5 OVER 5); 300HP MOTOR
SHEAR: 220T CRANK TYPE: 2 X 400HP MOTORS
BUNDLING SECTION: 16” (400 MM) NOMINAL BUNDLE SIZE
INVENTORY ID 200818-100-00
| INVENTORY ID | 20081810000 |
| TITLE | STRAIGHTEN AND SHEAR LINE FOR ANGLES, CHANNELS AND FLATS (NCO) |
| PREVIOUS USE | CONTINUOUS CUT LINE FOR SHAPED |
| MANUFACTURER OF EQUIPMENT | SIMAC |
| YEAR OF MANUFACTURE | 1997 |
| MATERIAL PROCESSED (STEEL, STAINLESS, ETC.) | STEEL |
| TYPE (NON-CONT. OR CONTINUOUS) | CONTINUOUS |
| DIRECTION OF TRAVEL (VIEWED FROM OPERATORS SIDE) | LEFT TO RIGHT (VIEWED FROM OPERATOR'S SIDE) |
