QTY (4) 80 FEET OF INDIVIDUALLY DRIVEN ROLL TABLES FOR 16" BUNDLES OF BEAMS, ANGLES, AND FLATS, TOTAL 320 FT
 "20081800600 QTY (4) 80 FEET OF INDIVIDUALLY DRIVEN ROLL TABLES FOR 16\" BUNDLES OF BEAMS, ANGLES, AND FLATS, TOTAL 320 FT")
80 FEET OF INDIVIDUALLY DRIVEN ROLL TABLES FOR 16 INCH DIAMETER BUNDLES
MANUFACTURER: SIMAC
YEAR: 1993
20 ROLLS WITH VERTICAL SIDE ROLLERS 15" HIGH 5" DIAMETER
AND MANUAL WHEEL ADJUSTED APRON TYPE SIDE GUIDES
CONSISTS OF 4 TABLES 5 ROLLS EACH ON 4' CENTERS
9 1/2" DIAMETER WITH 17 3/4" FACE
PASS LINE: 26"
3 HP AC MOTOR
INVENTORY#: 200818-006-00
| INVENTORY ID | 20081800600 |
| TITLE | QTY (4) 80 FEET OF INDIVIDUALLY DRIVEN ROLL TABLES FOR 16" BUNDLES OF BEAMS, ANGLES, AND FLATS, TOTAL 320 FT |
| ROLL FACE | 17 3/4" |
| ROLL DIAMETER | 9 1/2" |
| MANUFACTURER OF EQUIPMENT | SIMAC |
| YEAR OF MANUFACTURE | 1993 |
| NUMBER OF ROLLS | 20 |
| MOTOR HP | 3 HP |
| MOTOR RPM | 1760 |
| MOTOR VOLTAGE TYPE (AC / DC) | AC |
