MECO 43" WIDE, .125 GAUGE, 2-HIGH TEMPER MILL
MANFACTURER: MECO
AGE: 1960's
GENERAL SPECIFICATIONS:
WIDTH: 43" (1092.2 MM)
GAUGE: 0.070" - 0.125" (1.78 MM - 3.18 MM)
MATERIAL ROLLED: FERROUS & NON FERROUS
ROLL CONFIGURATION: HORIZONTAL
ROLL DIAMETER: 14.25" (360 MM)
ROLL FACE: 43" ((1092.2 MM)
BEARING TYPE: FOUR ROW ROLLER
PREVIOUS USE: CLADDING LINE
DRIVE MOTOR: 10/15 HP, 230 VDC, ADJUSTABLE SPEED
GEARBOX: H&S, 35 HP RATING, 17.9:1 RATIO
HOUSING TYPE: CAST STEEL - CLOSED TOP
POST SIZE: 11" X 9" (280 MM X 279 MM)
WINDOW: 42" HEIGHT X 17.25" WIDTH (1067 MM X 438 MM)
SCREWDOWN: ELECTROMECHANICAL
FEATURES: ALREADY DISMANTLED
INVENTORY #: 200649-000-00
| INVENTORY ID | 20064900000 |
| TITLE | MECO 43" WIDE, .125 GAUGE, 2-HIGH TEMPER MILL |
| WORK ROLL DIA. | 14.25" |
| WORK ROLL FACE | 43" |
| ROLL CONFIGURATION (H/V) | HORIZONTAL |
| MANUFACTURER OF EQUIPMENT | MECO |
| YEAR OF MANUFACTURE | 1980'S |
| MATERIAL ROLLED (STNLESS, LO CARBON, HI CARBON) | FERROUS & NON FERROUS |
| MOTOR HP | 10/15 |
| MOTOR VOLTS | 230 |
| AC OR DC | DC |
| POST WIDTH | 11 |
| POST DEPTH | 9 |
| WINDOW HEIGHT | 42 |
| WINDOW WIDTH | 17.25 |
| HORIZONTAL GEARBOX RATIO (:1) | 17.9 |
| HORIZONTAL GEARBOX (INCREASER OR DECREASER) | DECREASER |
| FEATURES 1 | ALREADY DISMANTLED |
