1/2" X 72" BLISS SLITTING LINE
MANUFACTURER: MECO / BUTECH BLISS
GENERAL SPECIFICATIONS:
MATERIAL: MILD STEEL
STARTING COIL: 72" MAX (1830 MM)
80,000 PSI YIELD MINIMUM:.300" X 72"
40,000 PSI YIELD MAX GAUGE: .500" X 48"
MAX OUTSIDE DIAMETER:80" (2030 MM)
INSIDE DIAMETER: 24" TO 30" (610 TO 76 MM)
COIL WEIGHT: 80,000 LBS (36,287.4 KG)
FINISHED COIL: 42" TO 80" WIDE (1065 TO 2030 MM)
MINIMUM WIDTH: 0.060 TO 0.375" AT 72"
WIDE MAX GAUGE: 500" AT 48"
LINE SPEED: 130 TO 400 FPM (0.76 TO 2 MPS)
DIRECTION OF TRAVEL: LEFT TO RIGHT (VIEWED FROM OPERATOR SIDE)
SLITTER MOTOR: 2 X 75 HP, 650/1950 RPM
REDUCER: 25.24 RATIO
SLITTER ARBOR: 12" (300 MM)
KNIFE DIAMETER: 20" (508 MM)
UNCOILER: DUAL STUB MANDRELS
ENTRY PROCESSOR: 2 OVER 3 FLATTENER AND PINCH ROLL
RECOILER: TURRET TYPE
FEATURES: ALREADY DISMANTLED
SIDE TRIMMER AVAILABLE
INVENTORY #: 2005585-225-01
| INVENTORY ID | 20058522501 |
| TITLE | 1/2" X 72" BLISS SLITTING LINE |
| ENTRY COIL WIDTH MAX | 72" |
| ENTRY COIL GAUGE MAX | 1/2" |
| MANUFACTURER OF EQUIPMENT | BLISS |
| WIDTH | 72" |
| MATERIAL | MILD STEEL |
| ENTRY COIL WIDTH MIN | .300" |
| ENTRY COIL GAUGE MIN | .500" |
| ENTRY COIL O.D. MAX | 80" |
| ENTRY COIL I.D. MIN | 24" |
| ENTRY COIL I.D. MAX | 30" |
| ENTRY COIL WEIGHT | 80,000 LBS. |
| EXIT COIL WIDTH MIN | 42" |
| EXIT COIL WIDTH MAX | 80" |
