14 3/4" (375 MM) LUFKIN 2 HI COMBINATION PINION STAND
 "20041225000 14 3/4\" (375 MM) LUFKIN 2 HI COMBINATION PINION STAND")
 "20041225000 14 3/4\" (375 MM) LUFKIN 2 HI COMBINATION PINION STAND")
 "20041225000 14 3/4\" (375 MM) LUFKIN 2 HI COMBINATION PINION STAND")
 "20041225000 14 3/4\" (375 MM) LUFKIN 2 HI COMBINATION PINION STAND")
| INVENTORY ID | 20041225000 |
| TITLE | 14 3/4" (375 MM) LUFKIN 2 HI COMBINATION PINION STAND |
| PITCH DIAMETER | 14.75" |
| MANUFACTURER OF EQUIPMENT | LUFKIN |
| YEAR OF MANUFACTURE | 1998 |
| SERIAL NUMBER | 114274 |
| CONFIGURATION (VERTICAL/HORIZONTAL) | HORIZONTAL |
| RATED HP | 850 |
| RATED RPM | 800 |
| RATIO TO 1 | 6.2 |
| SVC FACTOR (1.0, 1.5 ETC) | 1.75 |
| SHAFT ARRANGEMENT | PARALLEL |
| HEIGHT TO CENTERLINE OF OUTPUT SHAFT | 38.58 |
| INPUT SHAFT DIA | 5.5 |
| OUTPUT SHAFT DIA | 9 |
| BRG LUBE AVAILABLE | YES |
| DIMENSION WIDE HOUSING | 56.5 |
| DIMENSION WIDE OVER SHAFTS | 77 |
| DIMENSION LONG | 80 |
| DIMENSION HIGH | 32.2 |
| WEIGHT | 22,400 |
| HOUSING TYPE | FAB |
| PREVIOUS USE | STAND 11 MILL DRIVE |
| FEATURES 1 | OIL CENTRAL LUBE |
