500 HP, 900 RPM, 4000 VOLT, WESTINGHOUSE, 4511, INDUCTION AC MOTOR
 "13078000000 500 HP, 900 RPM, 4000 VOLT, WESTINGHOUSE, 4511, INDUCTION AC MOTOR")
 "13078000000 500 HP, 900 RPM, 4000 VOLT, WESTINGHOUSE, 4511, INDUCTION AC MOTOR")
 "13078000000 500 HP, 900 RPM, 4000 VOLT, WESTINGHOUSE, 4511, INDUCTION AC MOTOR")
 "13078000000 500 HP, 900 RPM, 4000 VOLT, WESTINGHOUSE, 4511, INDUCTION AC MOTOR")
 "13078000000 500 HP, 900 RPM, 4000 VOLT, WESTINGHOUSE, 4511, INDUCTION AC MOTOR")
| INVENTORY ID | 13078000000 |
| TITLE | 500 HP, 900 RPM, 4000 VOLT, WESTINGHOUSE, 4511, INDUCTION AC MOTOR |
| HORSEPOWER | 500 |
| SPEED NAMEPLATE | 900 |
| VOLTAGE | 4000 |
| MANUFACTURER | WESTINGHOUSE |
| FRAME | 4511 |
| ENCLOSURE | WP1 |
| SHAFT | SESS |
| DESIGN | N/A |
| CODE | K |
| TYPE | N/A |
| INSULATION CLASS | F |
| BEARINGS | SEALED SLEEVE |
| SERVICE FACTOR | 1.15 |
| PHASE | 3 |
| FREQUENCY | 60 |
| AMPERAGE | FL83 |
| SERIAL NUMBER OR ID NUMBER | 5463AA-1 |
| MODEL NUMBER OR STYLE NUMBER | 1768993 |
| WEIGHT | 7,870 |
| DUTY | CONT |
| TEMPERATURE RISE | 40 |
| CAST IRON FRAME | NO |
| CAST ALUM FRAME | NO |
| LEADS FACING DRIVE END | RIGHT |
| SHAFT HEIGHT | 18" |
| DRIVE SHAFT DIAMETER | 4 7/8" |
| DRIVE SHAFT LENGTH | 11" |
