200 HP, 500/2000 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4362, DC MOTOR
 "12370100000 200 HP, 500/2000 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4362, DC MOTOR")
 "12370100000 200 HP, 500/2000 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4362, DC MOTOR")
 "12370100000 200 HP, 500/2000 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4362, DC MOTOR")
| INVENTORY ID | 12370100000 |
| TITLE | 200 HP, 500/2000 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4362, DC MOTOR |
| HORSEPOWER | 200 |
| SPEED | 500 |
| SPEED 2 | 2000 |
| VOLTAGE | 500 |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | CD4362 |
| WINDING | SHUNT |
| ENCLOSURE | SPFG-SV |
| SHAFT | SESS |
| AMPERAGE | 335 |
| DUTY | CONT |
| BEARINGS | A/F |
| FIELD VOLTAGE | 300 / 150 |
| FIELD AMPERAGE | 10.8 / 2.4 |
| FIELD RESISTANCE | 20 @ 25 DEGREE CELCIUS |
| DEGREE OF TEMPERATURE RISE | 40 |
| SERIAL NUMBER OR ID NUMBER | PF-2-23 RF |
| MODEL NUMBER OR STYLE NUMBER | 5CD435GA807C801 |
| INSULATION CLASS | F |
| POWER SUPPLY CODE | C |
| WEIGHT | 5,850 |
| DRIVE SHAFT DIMENSION | 4 1/2" |
| DRIVE SHAFT LENGTH | 8" |
| BRAKE SHAFT DIAMETER | N/A |
| BRAKE SHAFT LENGTH | N/A |
| SHAFT HEIGHT | 15" |
| MOTOR LENGTH | 75" |
| WIDTH BETWEEN FEET | 30" |
| LENGTH BETWEEN FEET | 45" |
