500 HP, 650/1200 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4562, DC MOTOR
 "12369800000 500 HP, 650/1200 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4562, DC MOTOR")
 "12369800000 500 HP, 650/1200 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4562, DC MOTOR")
| INVENTORY ID | 12369800000 |
| TITLE | 500 HP, 650/1200 RPM, 500 VOLT GENERAL ELECTRIC, SHUNT, CD4562, DC MOTOR |
| HORSEPOWER | 500 |
| SPEED | 650 |
| SPEED 2 | 1200 |
| VOLTAGE | 500 |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | CD4562 |
| WINDING | SHUNT |
| ENCLOSURE | SPFG-SV |
| SHAFT | SESS |
| AMPERAGE | 815 |
| DUTY | CONT |
| BEARINGS | A/F |
| FIELD VOLTAGE | 240 / 120 |
| FIELD AMPERAGE | 16.9 / 8.0 |
| FIELD RESISTANCE | 10.7 @ 25 DEGREE CELCIUS |
| DEGREE OF TEMPERATURE RISE | 40 |
| SERIAL NUMBER OR ID NUMBER | JW-2-66 |
| MODEL NUMBER OR STYLE NUMBER | 5CD454LA00IA004 |
| SERVICE FACTOR | 1.15 |
| INSULATION CLASS | F |
| POWER SUPPLY CODE | C |
| WEIGHT | 11,110 |
| DRIVE SHAFT DIMENSION | 6" |
| DRIVE SHAFT LENGTH | 11" |
| BRAKE SHAFT DIAMETER | N/A |
| BRAKE SHAFT LENGTH | N/A |
| SHAFT HEIGHT | 21" |
| MOTOR LENGTH | 74" |
| WIDTH BETWEEN FEET | 42" |
| LENGTH BETWEEN FEET | 45" |
