200 HP, 1150/1380 RPM, 500 VOLT, RELIANCE, B506ATZ, COMPOUND, USED DC MOTOR
 "12304100000 200 HP, 1150/1380 RPM, 500 VOLT, RELIANCE, B506ATZ, COMPOUND, USED DC MOTOR")
 "12304100000 200 HP, 1150/1380 RPM, 500 VOLT, RELIANCE, B506ATZ, COMPOUND, USED DC MOTOR")
| INVENTORY ID | 12304100000 |
| TITLE | 200 HP, 1150/1380 RPM, 500 VOLT, RELIANCE, B506ATZ, COMPOUND, USED DC MOTOR |
| HORSEPOWER | 200 |
| SPEED | 1150 |
| SPEED 2 | 1380 |
| VOLTAGE | 500 |
| MANUFACTURER | RELIANCE |
| FRAME | B506ATZ |
| TYPE | TR |
| WINDING | STAB SHUNT |
| ENCLOSURE | SPSV |
| SHAFT | SESS |
| AMPERAGE | 319 |
| DUTY | CONT |
| BEARINGS | A/F |
| FIELD VOLTAGE | 240 |
| FIELD AMPERAGE | 9.70 / 6.72 |
| FIELD RESISTANCE | 24.4 |
| DEGREE OF TEMPERATURE RISE | 40 |
| SERIAL NUMBER OR ID NUMBER | 1DB847550-T1-OP |
| SERVICE FACTOR | 1.15 |
| INSULATION CLASS | F |
| POWER SUPPLY CODE | C |
| WEIGHT | 2,290 |
| DRIVE SHAFT DIMENSION | 3 5/8" |
| DRIVE SHAFT LENGTH | 7 1/4" |
| BRAKE SHAFT DIAMETER | N/A |
| BRAKE SHAFT LENGTH | N/A |
| SHAFT HEIGHT | 12 1/4" |
| MOTOR LENGTH | 43" |
| WIDTH BETWEEN FEET | 20" |
| LENGTH BETWEEN FEET | 20" |
