550 HP. 650 RPM, 500 VOLT, GENERAL ELECTRIC, CD6173, SHUNT, USED DC MOTOR
 "12298200000 550 HP. 650 RPM, 500 VOLT, GENERAL ELECTRIC, CD6173, SHUNT, USED DC MOTOR")
 "12298200000 550 HP. 650 RPM, 500 VOLT, GENERAL ELECTRIC, CD6173, SHUNT, USED DC MOTOR")
| INVENTORY ID | 12298200000 |
| TITLE | 550 HP. 650 RPM, 500 VOLT, GENERAL ELECTRIC, CD6173, SHUNT, USED DC MOTOR |
| HORSEPOWER | 550 |
| SPEED | 650 |
| VOLTAGE | 500 |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | CD6173 |
| TYPE | CD |
| WINDING | SHUNT |
| ENCLOSURE | DPFG-BV |
| SHAFT | SESS |
| AMPERAGE | 870 |
| DUTY | SHEAR |
| BEARINGS | A/F |
| FIELD VOLTAGE | 300 / 150 |
| FIELD AMPERAGE | FOR 300V /19.5 FOR 150 V / 39.0 |
| FIELD RESISTANCE | FOR 300V /10.9 FOR 150V / 2.7 |
| DEGREE OF TEMPERATURE RISE | 50 |
| SERIAL NUMBER OR ID NUMBER | SV-4-2 |
| MODEL NUMBER OR STYLE NUMBER | 5CD6152A806C80 |
| INSULATION CLASS | F |
| POWER SUPPLY CODE | C |
| WEIGHT | 9,300 |
| DRIVE SHAFT DIMENSION | 5 3/8" |
| DRIVE SHAFT LENGTH | 11" |
| BRAKE SHAFT DIAMETER | N/A |
| BRAKE SHAFT LENGTH | N/A |
| SHAFT HEIGHT | 17 1/2" |
| MOTOR LENGTH | 83" |
| WIDTH BETWEEN FEET | 35" |
| LENGTH BETWEEN FEET | 57" |
