125 HP, 1175 RPM, WESTINGHOUSE, 449TX, AC SLIP RING CRANE MOTOR
 "12295000000 125 HP, 1175 RPM, WESTINGHOUSE, 449TX, AC SLIP RING CRANE MOTOR")
 "12295000000 125 HP, 1175 RPM, WESTINGHOUSE, 449TX, AC SLIP RING CRANE MOTOR")
| INVENTORY ID | 12295000000 |
| TITLE | 125 HP, 1175 RPM, WESTINGHOUSE, 449TX, AC SLIP RING CRANE MOTOR |
| HORSEPOWER | 125 |
| SPEED | 1175 |
| STATOR VOLTAGE 1 | 460 |
| STATOR VOLTAGE 2 | 385 |
| MANUFACTURER | WESTINGHOUSE |
| FRAME | 449TX |
| SHAFT HEIGHT | 11" |
| ROTOR AMPS | 147 |
| ROTOR VOLTS | 460 |
| SHAFT EXTENSION | 1T1S |
| ENCLOSURE | TENV |
| STATOR AMPS | 150 |
| BEARINGS | A/F |
| MODEL NUMBER OR STYLE NUMBER | 77C23241 |
| SERIAL NUMBER OR ID NUMBER | 7710 |
| PHASE | 3 |
| DEGREE OF TEMPERATURE RISE | 40 |
| YEAR OF MANUFACTURE | N/A |
| DRIVE SHAFT DIAMETER | 3 3/8" |
| DRIVE SHAFT LENGTH | 5 1/2" |
| BRAKE SHAFT DIAMETER | 2 5/8" |
| BRAKE SHAFT LENGTH | 9 3/4" |
| OVERALL LENGTH | 61" |
| FRONT BOLT HOLE TO SHAFT | 13 1/2" |
| WIDTH BETWEEN FEET | 18" |
| LENGTH BETWEEN FEET | 25" |
