100 HP, 1185 RPM, 230/460V, WEG, 444/5T, INDUCTION AC MOTOR

INVENTORY ID	12294700000
TITLE	100 HP, 1185 RPM, 230/460V, WEG, 444/5T, INDUCTION AC MOTOR
HORSEPOWER	100
SPEED NAMEPLATE	1185
VOLTAGE	230
VOLTAGE 2	460
MANUFACTURER	WEG
FRAME	444/5T
ENCLOSURE	TEFC
SHAFT	SESS
DESIGN	B
CODE	G
INSULATION CLASS	F
BEARINGS	A/F
SERVICE FACTOR	1.15
PHASE	3
FREQUENCY	60
AMPERAGE	242/121
SERIAL NUMBER OR ID NUMBER	28SET2017
MODEL NUMBER OR STYLE NUMBER	104081825
WEIGHT	1,678
DUTY	CONT
TEMPERATURE RISE	40
CAST IRON FRAME	YES
CAST ALUM FRAME	NO
LEADS FACING DRIVE END	LEFT
SHAFT HEIGHT	10 3/4"
DRIVE SHAFT DIAMETER	3 3/8"
DRIVE SHAFT LENGTH	8 1/2"
BRAKE SHAFT DIAMETER	N/A
BRAKE SHAFT LENGTH	N/A
