115 HP, 565 RPM, 4400V, GENERAL ELECTRIC, 8188Z, INDUCTION AC MOTOR

INVENTORY ID	12292300000
TITLE	115 HP, 565 RPM, 4400V, GENERAL ELECTRIC, 8188Z, INDUCTION AC MOTOR
HORSEPOWER	115
SPEED NAMEPLATE	565
SPEED SYNCHRONOUS	N/A
VOLTAGE	440
MANUFACTURER	GENERAL ELECTRIC
FRAME	8188Z
ENCLOSURE	DP
SHAFT	1T1S
DESIGN	N/A
CODE	H
TYPE	KR
INSULATION CLASS	N/A
BEARINGS	A/F
SERVICE FACTOR	N/A
PHASE	3
FREQUENCY	60
AMPERAGE	150
SERIAL NUMBER OR ID NUMBER	DS8422992
MODEL NUMBER OR STYLE NUMBER	5KR818847A9
WEIGHT	2,650
DUTY	CONT
TEMPERATURE RISE	90
CAST IRON FRAME	YES
CAST ALUM FRAME	NO
LEADS FACING DRIVE END	LEFT
SHAFT HEIGHT	13"
DRIVE SHAFT DIAMETER	2 7/8"
DRIVE SHAFT LENGTH	5 1/2"
BRAKE SHAFT LENGTH	7"
