1600 HP (1200 KW), 306 RPM, 579V, SIEMENS, 8010S, INVERTER MOTOR
 "12257900000 1600 HP (1200 KW), 306 RPM, 579V, SIEMENS, 8010S, INVERTER MOTOR")
 "12257900000 1600 HP (1200 KW), 306 RPM, 579V, SIEMENS, 8010S, INVERTER MOTOR")
 "12257900000 1600 HP (1200 KW), 306 RPM, 579V, SIEMENS, 8010S, INVERTER MOTOR")
 "12257900000 1600 HP (1200 KW), 306 RPM, 579V, SIEMENS, 8010S, INVERTER MOTOR")
| INVENTORY ID | 12257900000 |
| TITLE | 1600 HP (1200 KW), 306 RPM, 579V, SIEMENS, 8010S, INVERTER MOTOR |
| HORSEPOWER | 1600 (1200 KW) |
| SPEED | 306 |
| VOLTAGE | 579 |
| MANUFACTURER | SIEMENS |
| FRAME | 636S |
| ENCLOSURE | TE |
| SHAFT | DESS |
| DESIGN | N/A |
| CODE | J |
| TYPE | CAZBB |
| INSULATION CLASS | F-VPI |
| BEARINGS | A/F |
| SERVICE FACTOR | 1.00 |
| PHASE | 3 |
| FREQUENCY | 25.67 |
| AMPERAGE | 1597 |
| SERIAL NUMBER OR ID NUMBER | 8002985582-30 |
| WEIGHT | 31,670 |
| DUTY | CONT |
| TEMPERATURE RISE | 40 |
| CAST IRON FRAME | YES |
| CAST ALUM FRAME | NO |
| LEADS FACING DRIVE END | RIGHT |
| SHAFT HEIGHT | 25" |
| DRIVE SHAFT DIAMETER | 8 3/4" |
| DRIVE SHAFT LENGTH | 12" |
| BRAKE SHAFT DIAMETER | 4 3/8" |
| BRAKE SHAFT LENGTH | 8" |
