150 HP, 870 RPM, 460 VOLT, WESTINGHOUSE, 5008LS INDUCTION AC MOTOR
 "12244400000 150 HP, 870 RPM, 460 VOLT, WESTINGHOUSE, 5008LS INDUCTION AC MOTOR")
 "12244400000 150 HP, 870 RPM, 460 VOLT, WESTINGHOUSE, 5008LS INDUCTION AC MOTOR")
 "12244400000 150 HP, 870 RPM, 460 VOLT, WESTINGHOUSE, 5008LS INDUCTION AC MOTOR")
| INVENTORY ID | 12244400000 |
| TITLE | 150 HP, 870 RPM, 460 VOLT, WESTINGHOUSE, 5008LS INDUCTION AC MOTOR |
| HORSEPOWER | 150 |
| SPEED NAMEPLATE | 870 |
| VOLTAGE | 460 |
| MANUFACTURER | WESTINGHOUSE |
| FRAME | 5008LS |
| ENCLOSURE | TEFC |
| SHAFT | DETS |
| TYPE | LAC |
| INSULATION CLASS | B |
| BEARINGS | A/F |
| PHASE | 3 |
| FREQUENCY | 60 |
| AMPERAGE | 170 |
| SERIAL NUMBER OR ID NUMBER | 1S-80 |
| MODEL NUMBER OR STYLE NUMBER | 801F13588 |
| WEIGHT | 3,725 |
| DUTY | CONT |
| TEMPERATURE RISE | 40 |
| CAST IRON FRAME | YES |
| CAST ALUM FRAME | NO |
| LEADS FACING DRIVE END | LEFT |
| SHAFT HEIGHT | 12 1/2" |
| DRIVE SHAFT DIAMETER | 3 3/8" |
| DRIVE SHAFT LENGTH | 7" |
| BRAKE SHAFT DIAMETER | 2 7/8" |
| BRAKE SHAFT LENGTH | 6" |
