200 HP, 1780 RPM, 460 VOLT, RELIANCE, 445TDZ FLANGE, INDUCTION AC MOTOR
 "12242500000 200 HP, 1780 RPM, 460 VOLT, RELIANCE, 445TDZ FLANGE, INDUCTION AC MOTOR")
 "12242500000 200 HP, 1780 RPM, 460 VOLT, RELIANCE, 445TDZ FLANGE, INDUCTION AC MOTOR")
 "12242500000 200 HP, 1780 RPM, 460 VOLT, RELIANCE, 445TDZ FLANGE, INDUCTION AC MOTOR")
| INVENTORY ID | 12242500000 |
| TITLE | 200 HP, 1780 RPM, 460 VOLT, RELIANCE, 445TDZ FLANGE, INDUCTION AC MOTOR |
| HORSEPOWER | 200 |
| SPEED NAMEPLATE | 1780 |
| VOLTAGE | 460 |
| MANUFACTURER | RELIANCE |
| FRAME | 445TDZ |
| ENCLOSURE | DPBB |
| SHAFT | SESS |
| DESIGN | Y |
| CODE | G |
| TYPE | P |
| INSULATION CLASS | F |
| BEARINGS | A/F |
| SERVICE FACTOR | 1.15 |
| PHASE | 3 |
| FREQUENCY | 60 |
| AMPERAGE | 228 |
| SERIAL NUMBER OR ID NUMBER | 1MAF73750 |
| MODEL NUMBER OR STYLE NUMBER | N/A |
| WEIGHT | 1,700 |
| DUTY | CONT |
| TEMPERATURE RISE | 40 |
| CAST IRON FRAME | YES |
| CAST ALUM FRAME | NO |
| LEADS FACING DRIVE END | LEFT |
| SHAFT HEIGHT | 11 1/4" |
| DRIVE SHAFT DIAMETER | 2 3/8" |
| DRIVE SHAFT LENGTH | 3 1/2" |
