2000/2300 KVA, 22,900 PRI, 480 SEC, RE UPTEGRAFF, OUTDOOR, TRANSFORMER, USED POWER TRANSFORMER

INVENTORY ID	12156500000
TITLE	2000/2300 KVA, 22,900 PRI, 480 SEC, RE UPTEGRAFF, OUTDOOR, TRANSFORMER, USED POWER TRANSFORMER
RATING	2000
PRIMARY VOLTAGE	22,900
SECONDARY VOLTAGE	480
MANUFACTURER	UPTEGRAFF
PHASE	3
HERTZ	60
AGE	1981
TAPS ABOVE AND BELOW	2 ABOVE - 2 BELOW
TAPS VOLTAGES	A-24,100 , B-23,500, C-22,100, D-22300, E-21,700
IMPEDANCE	2000 KVA 5.8%, 2300 KVA, 6.8%
TYPE	FLUID
WEIGHT	13,250
CLASS	OA/FFA
SERIAL NUMBER	14E81
TEMPERATURE RISE	65 DEGREE C
DEPTH	65"
WIDTH	81"
HEIGHT	89"
