1100 HP, 1192 RPM, 500 VOLT, GENERAL ELECTRIC, CD4670, SHUNT USED DC MOTOR
 "12078500000 1100 HP, 1192 RPM, 500 VOLT, GENERAL ELECTRIC, CD4670, SHUNT USED DC MOTOR")
 "12078500000 1100 HP, 1192 RPM, 500 VOLT, GENERAL ELECTRIC, CD4670, SHUNT USED DC MOTOR")
| INVENTORY ID | 12078500000 |
| TITLE | 1100 HP, 1192 RPM, 500 VOLT, GENERAL ELECTRIC, CD4670, SHUNT USED DC MOTOR |
| HORSEPOWER | 1100 |
| SPEED | 1192 |
| VOLTAGE | 500 |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | 4670 |
| TYPE | CD |
| WINDING | SHUNT |
| ENCLOSURE | DPFG-BV |
| SHAFT | SESS |
| AMPERAGE | 1730 |
| DUTY | CONT |
| BEARINGS | A/F |
| FIELD VOLTAGE | 325 |
| FIELD AMPERAGE | 8.95 |
| FIELD RESISTANCE | 29.1 |
| DEGREE OF TEMPERATURE RISE | 40 |
| SERIAL NUMBER OR ID NUMBER | UA-2-20 |
| MODEL NUMBER OR STYLE NUMBER | 5CD463PA808C800 |
| INSULATION CLASS | F |
| POWER SUPPLY CODE | C |
| WEIGHT | 13,700 |
| DRIVE SHAFT DIMENSION | 13 1/2" |
| SHAFT HEIGHT | 27" |
| MOTOR LENGTH | 83.38" |
| WIDTH BETWEEN FEET | 52" |
| LENGTH BETWEEN FEET | 48" |
