QTY. (2) 265 HP, 900 RPM, 480V, RELIANCE, L4034, INVERTER DUTY AC MOTOR
 "12050100000 QTY. (2) 265 HP, 900 RPM, 480V, RELIANCE, L4034, INVERTER DUTY AC MOTOR")
 "12050100000 QTY. (2) 265 HP, 900 RPM, 480V, RELIANCE, L4034, INVERTER DUTY AC MOTOR")
 "12050100000 QTY. (2) 265 HP, 900 RPM, 480V, RELIANCE, L4034, INVERTER DUTY AC MOTOR")
 "12050100000 QTY. (2) 265 HP, 900 RPM, 480V, RELIANCE, L4034, INVERTER DUTY AC MOTOR")
| INVENTORY ID | 12050100000 |
| TITLE | QTY. (2) 265 HP, 900 RPM, 480V, RELIANCE, L4034, INVERTER DUTY AC MOTOR |
| HORSEPOWER | 265 |
| SPEED | 900 |
| VOLTAGE | 480 |
| MANUFACTURER | RELIANCE |
| FRAME | L4034 |
| ENCLOSURE | DPFV |
| SHAFT | DESS |
| DESIGN | L1331A |
| INSULATION CLASS | H |
| BEARINGS | A/F |
| SERVICE FACTOR | 1 |
| PHASE | 3 |
| FREQUENCY | 30.6 |
| AMPERAGE | 293 |
| SERIAL NUMBER OR ID NUMBER | D1K226490-KATI |
| WEIGHT | 2,190 |
| DUTY | CONT |
| TEMPERATURE RISE | 40 |
| CAST IRON FRAME | YES |
| LEADS FACING DRIVE END | RIGHT |
| SHAFT HEIGHT | 10" |
| DRIVE SHAFT DIAMETER | 3 5/8" |
| DRIVE SHAFT LENGTH | 7 1/4" |
| BRAKE SHAFT DIAMETER | 3 5/8" |
| BRAKE SHAFT LENGTH | 7 3/4" |
