150 HP, 1780 RPM, 230V, US ELECTRIC, 445T INDUCTION AC MOTOR
 "11790300000 150 HP, 1780 RPM, 230V, US ELECTRIC, 445T INDUCTION AC MOTOR")
| INVENTORY ID | 11790300000 |
| TITLE | 150 HP, 1780 RPM, 230V, US ELECTRIC, 445T INDUCTION AC MOTOR |
| HORSEPOWER | 150 |
| SPEED NAMEPLATE | 1780 |
| SPEED SYNCHRONOUS | 1800 |
| VOLTAGE | 460 |
| MANUFACTURER | US ELECTRIC |
| FRAME | 445T |
| ENCLOSURE | TEFC |
| SHAFT | SESS |
| DESIGN | B |
| CODE | F |
| TYPE | CT |
| INSULATION CLASS | F |
| BEARINGS | A/F |
| SERVICE FACTOR | 1.15 |
| PHASE | 3 |
| FREQUENCY | 60 |
| AMPERAGE | 174 |
| SERIAL NUMBER OR ID NUMBER | F232-2102222R108R |
| WEIGHT | 1,465 |
| DUTY | CONT |
| TEMPERATURE RISE | 40 |
| CAST IRON FRAME | YES |
| CAST ALUM FRAME | NO |
| LEADS FACING DRIVE END | LEFT |
| SHAFT HEIGHT | 11" |
| DRIVE SHAFT DIAMETER | 3 3/8" |
| DRIVE SHAFT LENGTH | 8 7/16" |
