5 HP, 1750/3000 RPM, 240 VOLT, GENERAL ELECTRIC, SHUNT, CD256, DC MOTOR

INVENTORY ID	11494200000
TITLE	5 HP, 1750/3000 RPM, 240 VOLT, GENERAL ELECTRIC, SHUNT, CD256, DC MOTOR
HORSEPOWER	5
SPEED	1750
SPEED 2	3000
VOLTAGE	240
MANUFACTURER	GENERAL ELECTRIC
FRAME	CD256
TYPE	CD
WINDING	SHUNT
ENCLOSURE	TEFC
SHAFT	SESS
AMPERAGE	185
DUTY	CONT
BEARINGS	A/F
FIELD AMPERAGE	.805 / .40
FIELD RESISTANCE	216
DEGREE OF TEMPERATURE RISE	75
SERIAL NUMBER OR ID NUMBER	NTI-66
MODEL NUMBER OR STYLE NUMBER	5CD256F119
SERVICE FACTOR	1.0
WEIGHT	225
DRIVE SHAFT DIMENSION	1 3/8"
DRIVE SHAFT LENGTH	3 3/4"
BRAKE SHAFT DIAMETER	N/A
BRAKE SHAFT LENGTH	N/A
SHAFT HEIGHT	6 1/4
SHAFT LENGTH	N/A
WIDTH BETWEEN FEET	10"
LENGTH BETWEEN FEET	10"
