300 HP, 1770 RPM, 2300V, SIEMENS, 449TS INDUCTION AC MOTOR
 "11484800000 300 HP, 1770 RPM, 2300V, SIEMENS, 449TS INDUCTION AC MOTOR")
 "11484800000 300 HP, 1770 RPM, 2300V, SIEMENS, 449TS INDUCTION AC MOTOR")
 "11484800000 300 HP, 1770 RPM, 2300V, SIEMENS, 449TS INDUCTION AC MOTOR")
| INVENTORY ID | 11484800000 |
| TITLE | 300 HP, 1770 RPM, 2300V, SIEMENS, 449TS INDUCTION AC MOTOR |
| HORSEPOWER | 300 |
| SPEED NAMEPLATE | 1770 |
| SPEED SYNCHRONOUS | 1800 |
| VOLTAGE | 2300 |
| MANUFACTURER | SIEMENS |
| FRAME | 449TS |
| ENCLOSURE | DP |
| SHAFT | SESS |
| DESIGN | A |
| CODE | H |
| TYPE | RG |
| INSULATION CLASS | F |
| BEARINGS | AF |
| SERVICE FACTOR | 1.0 |
| PHASE | 3 |
| FREQUENCY | 60 |
| AMPERAGE | 71.5 |
| SERIAL NUMBER OR ID NUMBER | 1-5111-61950-1-1 |
| MODEL NUMBER OR STYLE NUMBER | 126 |
| WEIGHT | 1,650 |
| DUTY | CONT |
| TEMPERATURE RISE | 85 |
| CAST IRON FRAME | YES |
| CAST ALUM FRAME | NO |
| LEADS FACING DRIVE END | LEFT |
| SHAFT HEIGHT | 11" |
| DRIVE SHAFT DIAMETER | 3 3/8" |
| DRIVE SHAFT LENGTH | 6 3/4" |
