QTY (2) 25 HP, 500/2000 RPM, 500V, GENERAL ELECTRIC, CD407 AT, SHUNT, USED DC MOTOR
| INVENTORY ID | 11421900000 |
| TITLE | QTY (2) 25 HP, 500/2000 RPM, 500V, GENERAL ELECTRIC, CD407 AT, SHUNT, USED DC MOTOR |
| HORSEPOWER | 25 |
| SPEED | 500 |
| SPEED 2 | 2000 |
| VOLTAGE | 500 |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | 407AT |
| TYPE | CD |
| WINDING | SHUNT |
| ENCLOSURE | TEAAC |
| SHAFT | SESS |
| AMPERAGE | 41 |
| DUTY | CONT |
| BEARINGS | A/F |
| FIELD VOLTAGE | 300/150 |
| FIELD AMPERAGE | 4.95/1.0 |
| FIELD RESISTANCE | 45.1 |
| DEGREE OF TEMPERATURE RISE | 40 |
| SERIAL NUMBER OR ID NUMBER | CL-7-111-CL |
| MODEL NUMBER OR STYLE NUMBER | 5CD203JA009A802 |
| INSULATION CLASS | F |
| POWER SUPPLY CODE | C |
| DRIVE SHAFT DIMENSION | 2 5/8" |
| DRIVE SHAFT LENGTH | 5 1/2" |
| SHAFT HEIGHT | 10 1/2" |
| MOTOR LENGTH | 40" |
| WIDTH BETWEEN FEET | 16 1/2" |
| LENGTH BETWEEN FEET | 18" |
