250 HP, 1785 RPM, 460 V, SIEMENS, 447T, INDUCTION AC MOTOR
 "11365100000 250 HP, 1785 RPM, 460 V, SIEMENS, 447T, INDUCTION AC MOTOR")
 "11365100000 250 HP, 1785 RPM, 460 V, SIEMENS, 447T, INDUCTION AC MOTOR")
| INVENTORY ID | 11365100000 |
| TITLE | 250 HP, 1785 RPM, 460 V, SIEMENS, 447T, INDUCTION AC MOTOR |
| HORSEPOWER | 250 |
| SPEED NAMEPLATE | 1785 |
| SPEED SYNCHRONOUS | 1800 |
| VOLTAGE | 460 |
| MANUFACTURER | SIEMENS |
| FRAME | 447T |
| ENCLOSURE | TEFC |
| SHAFT | SESS |
| DESIGN | B |
| CODE | G |
| TYPE | RG2 |
| INSULATION CLASS | F |
| BEARINGS | A/F |
| SERVICE FACTOR | 60 |
| PHASE | 3 |
| FREQUENCY | 60 |
| AMPERAGE | 285 |
| SERIAL NUMBER OR ID NUMBER | 1LAO4474TF41C |
| WEIGHT | 1,695 |
| DUTY | CONTINUOUS |
| TEMPERATURE RISE | 40 |
| CAST IRON FRAME | YES |
| LEADS FACING DRIVE END | NO |
| SHAFT HEIGHT | 10 1/2" |
| DRIVE SHAFT DIAMETER | 3 1/2" |
| DRIVE SHAFT LENGTH | 8 1/2" |
