100HP, 500/2000RPM, 240V, WESTINGHOUSE, 586, SHUNT USED DC MOTOR
 "11254000000 100HP, 500/2000RPM, 240V, WESTINGHOUSE, 586, SHUNT USED DC MOTOR")
 "11254000000 100HP, 500/2000RPM, 240V, WESTINGHOUSE, 586, SHUNT USED DC MOTOR")
 "11254000000 100HP, 500/2000RPM, 240V, WESTINGHOUSE, 586, SHUNT USED DC MOTOR")
| INVENTORY ID | 11254000000 |
| TITLE | 100HP, 500/2000RPM, 240V, WESTINGHOUSE, 586, SHUNT USED DC MOTOR |
| HORSEPOWER | 100 HP |
| SPEED | 500 RPM |
| SPEED 2 | 2000 RPM |
| VOLTAGE | 240 VOLT |
| MANUFACTURER | WESTINGHOUSE |
| FRAME | 586 |
| TYPE | ADZ |
| WINDING | SHUNT |
| ENCLOSURE | DPBV |
| SHAFT | SESS |
| AMPERAGE | 343 |
| DUTY | 60 |
| BEARINGS | A/F |
| FIELD VOLTAGE | 150 |
| FIELD AMPERAGE | 14.8/2.14 |
| DEGREE OF TEMPERATURE RISE | 40 |
| SERIAL NUMBER OR ID NUMBER | 1S-79 |
| MODEL NUMBER OR STYLE NUMBER | 79F56570 |
| SERVICE FACTOR | 1.0 |
| INSULATION CLASS | CLF |
| POWER SUPPLY CODE | E |
| DRIVE SHAFT DIMENSION | 3 1/4 |
| DRIVE SHAFT LENGTH | 11 |
| SHAFT HEIGHT | 14 1/2 |
| SHAFT LENGTH | 59 |
| WIDTH BETWEEN FEET | 23 |
| LENGTH BETWEEN FEET | 22 |
