600HP, 1200RPM, 2300V, ALLIS CHALMERS, 30KK56, INDUCTION AC MOTOR
 "11251100000 600HP, 1200RPM, 2300V, ALLIS CHALMERS, 30KK56, INDUCTION AC MOTOR")
 "11251100000 600HP, 1200RPM, 2300V, ALLIS CHALMERS, 30KK56, INDUCTION AC MOTOR")
 "11251100000 600HP, 1200RPM, 2300V, ALLIS CHALMERS, 30KK56, INDUCTION AC MOTOR")
| INVENTORY ID | 11251100000 |
| TITLE | 600HP, 1200RPM, 2300V, ALLIS CHALMERS, 30KK56, INDUCTION AC MOTOR |
| HORSEPOWER | 600 HP |
| SPEED NAMEPLATE | 1200 RPM |
| SPEED SYNCHRONOUS | 1800 |
| VOLTAGE | 2300 |
| MANUFACTURER | ALLIS CHALMERS |
| FRAME | 30KK56 |
| ENCLOSURE | TEFC |
| SHAFT | SESS |
| BEARINGS | SLEAVE |
| PHASE | 3 |
| AMPERAGE | 135 |
| MODEL NUMBER OR STYLE NUMBER | 1-5110-06824-1-1 |
| WEIGHT | 5,700 |
| DUTY | CONTINUOUS |
| TEMPERATURE RISE | 40 |
| CAST IRON FRAME | NO |
| CAST ALUM FRAME | NO |
| LEADS FACING DRIVE END | LEFT |
| SHAFT HEIGHT | 26 |
| DRIVE SHAFT DIAMETER | 3 7/8 |
| DRIVE SHAFT LENGTH | 7 1/2 |
