400 HP, 500/1200 RPM, 500V, GENERAL ELECTRIC, CD6583, SHUNT, USED DC MOTOR
 "10781802800 400 HP, 500/1200 RPM, 500V, GENERAL ELECTRIC, CD6583, SHUNT, USED DC MOTOR")
| INVENTORY ID | 10781802800 |
| TITLE | 400 HP, 500/1200 RPM, 500V, GENERAL ELECTRIC, CD6583, SHUNT, USED DC MOTOR |
| HORSEPOWER | 400 |
| SPEED | 500 |
| SPEED 2 | 1200 |
| VOLTAGE | 500 |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | 6583 |
| TYPE | CD |
| WINDING | SHUNT |
| ENCLOSURE | DPFG |
| SHAFT | SESS |
| AMPERAGE | 660 |
| DUTY | CONT |
| BEARINGS | A/F |
| FIELD AMPERAGE | 12.6 / 4.5 |
| FIELD RESISTANCE | 12.4 |
| DEGREE OF TEMPERATURE RISE | 40 |
| SERIAL NUMBER OR ID NUMBER | TC-2-9- TC |
| MODEL NUMBER OR STYLE NUMBER | 5CD26E28G90068 |
| INSULATION CLASS | F |
| POWER SUPPLY CODE | C |
| WEIGHT | 13,500 |
| DRIVE SHAFT DIMENSION | 5 3/8" |
| DRIVE SHAFT LENGTH | 10 1/2" |
| SHAFT HEIGHT | 24 1/4" |
| MOTOR LENGTH | 74" |
| WIDTH BETWEEN FEET | 41" |
| LENGTH BETWEEN FEET | 29" |
