75 HP, 3565 RPM,230/460V, GENERAL ELECTRIC, 365TSD, INDUCTION AC MOTOR
 "10666800000 75 HP, 3565 RPM,230/460V, GENERAL ELECTRIC, 365TSD, INDUCTION AC MOTOR")
 "10666800000 75 HP, 3565 RPM,230/460V, GENERAL ELECTRIC, 365TSD, INDUCTION AC MOTOR")
 "10666800000 75 HP, 3565 RPM,230/460V, GENERAL ELECTRIC, 365TSD, INDUCTION AC MOTOR")
| INVENTORY ID | 10666800000 |
| TITLE | 75 HP, 3565 RPM,230/460V, GENERAL ELECTRIC, 365TSD, INDUCTION AC MOTOR |
| HORSEPOWER | 75 HP |
| SPEED NAMEPLATE | 3565 RPM |
| SPEED SYNCHRONOUS | 3600 |
| VOLTAGE | 230 |
| VOLTAGE 2 | 460 |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | 365TSD |
| ENCLOSURE | TEFC |
| SHAFT | SESS |
| DESIGN | BFC |
| TYPE | K |
| INSULATION CLASS | F |
| BEARINGS | A/F |
| SERVICE FACTOR | 1.15 |
| PHASE | 3 |
| FREQUENCY | 60 |
| AMPERAGE | 170/85 |
| SERIAL NUMBER OR ID NUMBER | RJ6165237 |
| MODEL NUMBER OR STYLE NUMBER | 5K365HS178A |
| WEIGHT | 1,000 |
| DUTY | CONTINUOUS |
| TEMPERATURE RISE | 40 |
| SHAFT HEIGHT | 9 |
| DRIVE SHAFT DIAMETER | 1 7/8 |
| DRIVE SHAFT LENGTH | 4 1/2 |
