50 HP, 850/2500 RPM, 240V, GENERAL ELECTRIC, CD504, SHUNT USED DC MOTOR
 "10631100000 50 HP, 850/2500 RPM, 240V, GENERAL ELECTRIC, CD504, SHUNT USED DC MOTOR")
| INVENTORY ID | 10631100000 |
| TITLE | 50 HP, 850/2500 RPM, 240V, GENERAL ELECTRIC, CD504, SHUNT USED DC MOTOR |
| HORSEPOWER | 50 HP |
| SPEED | 850 RPM |
| SPEED 2 | 2500 RPM |
| VOLTAGE | 240 VOLT |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | 504 |
| TYPE | CD |
| WINDING | SHUNT |
| ENCLOSURE | DPFG |
| SHAFT | DESS |
| DUTY | CONTINUOUS |
| BEARINGS | A/F |
| SERIAL NUMBER OR ID NUMBER | XT1-224 |
| MODEL NUMBER OR STYLE NUMBER | 5CD504E141 |
| SERVICE FACTOR | 1.15 |
| DRIVE SHAFT DIMENSION | 3 7/8 |
| DRIVE SHAFT LENGTH | 8 3/8 |
| SHAFT HEIGHT | 12 1/2 |
| WIDTH BETWEEN FEET | 20 |
| LENGTH BETWEEN FEET | 16 |
