75 HP, 1150/1600 RPM, 240V, WESTINGHOUSE, 504A, SHUNT USED DC MOTOR
 "10541500000 75 HP, 1150/1600 RPM, 240V, WESTINGHOUSE, 504A, SHUNT USED DC MOTOR")
 "10541500000 75 HP, 1150/1600 RPM, 240V, WESTINGHOUSE, 504A, SHUNT USED DC MOTOR")
| INVENTORY ID | 10541500000 |
| TITLE | 75 HP, 1150/1600 RPM, 240V, WESTINGHOUSE, 504A, SHUNT USED DC MOTOR |
| HORSEPOWER | 75 HP |
| SPEED | 1150 RPM |
| SPEED 2 | 1600 RPM |
| VOLTAGE | 240 VOLT |
| MANUFACTURER | WESTINGHOUSE |
| FRAME | 504A |
| WINDING | SHUNT |
| ENCLOSURE | DP |
| SHAFT | DESS |
| AMPERAGE | 264 |
| DUTY | CONTINUOUS |
| BEARINGS | ROLLER |
| FIELD AMPERAGE | 3.8 |
| FIELD RESISTANCE | 60 |
| SERIAL NUMBER OR ID NUMBER | 2S-58 |
| DRIVE SHAFT DIMENSION | 2 1/2 |
| DRIVE SHAFT LENGTH | 5 1/4 |
| BRAKE SHAFT DIAMETER | 2 7/8 |
| BRAKE SHAFT LENGTH | 8 1/2 |
| SHAFT HEIGHT | 12 1/6 |
| SHAFT LENGTH | 48 |
| WIDTH BETWEEN FEET | 20 |
| LENGTH BETWEEN FEET | 15 1/2 |
