20 HP, 800/1000 RPM, 480V, GENERAL ELECTRIC, CD405, SHUNT USED DC MOTOR
 "10502600000 20 HP, 800/1000 RPM, 480V, GENERAL ELECTRIC, CD405, SHUNT USED DC MOTOR")
| INVENTORY ID | 10502600000 |
| TITLE | 20 HP, 800/1000 RPM, 480V, GENERAL ELECTRIC, CD405, SHUNT USED DC MOTOR |
| HORSEPOWER | 20 HP |
| SPEED | 800 RPM |
| SPEED 2 | 1000 RPM |
| VOLTAGE | 480 VOLT |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | 405 |
| TYPE | CD |
| WINDING | SHUNT |
| ENCLOSURE | DPFG |
| SHAFT | SESS |
| AMPERAGE | 36 |
| DUTY | CONTINUOUS |
| BEARINGS | A/F |
| FIELD AMPERAGE | 2.64/2.0 |
| FIELD RESISTANCE | 70.4 |
| DEGREE OF TEMPERATURE RISE | 60 |
| SERIAL NUMBER OR ID NUMBER | GB1-152 |
| MODEL NUMBER OR STYLE NUMBER | 5CD405E307 |
| SERVICE FACTOR | 1.15 |
| DRIVE SHAFT DIMENSION | 2-3/8 |
| SHAFT HEIGHT | 10 |
| MOTOR LENGTH | 39 |
| WIDTH BETWEEN FEET | 16 |
| LENGTH BETWEEN FEET | 14 |
