15 HP, 500/2000 RPM, 240V, GENERAL ELECTRIC, CD445, SHUNT USED DC MOTOR
 "10480600000 15 HP, 500/2000 RPM, 240V, GENERAL ELECTRIC, CD445, SHUNT USED DC MOTOR")
| INVENTORY ID | 10480600000 |
| TITLE | 15 HP, 500/2000 RPM, 240V, GENERAL ELECTRIC, CD445, SHUNT USED DC MOTOR |
| HORSEPOWER | 15 HP |
| SPEED | 500 RPM |
| SPEED 2 | 2000 RPM |
| VOLTAGE | 240 VOLT |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | 445 |
| TYPE | CD |
| WINDING | SHUNT |
| ENCLOSURE | TEFC |
| SHAFT | SESS |
| AMPERAGE | 54 |
| DUTY | CONTINUOUS |
| BEARINGS | BALL |
| FIELD AMPERAGE | 1.92/.37 |
| FIELD RESISTANCE | 90 |
| SERIAL NUMBER OR ID NUMBER | EB-1-704 |
| MODEL NUMBER OR STYLE NUMBER | 5CD445F64 |
| SERVICE FACTOR | 1.0 |
| DRIVE SHAFT DIMENSION | 2 5/8 |
| DRIVE SHAFT LENGTH | 7 3/4 |
| SHAFT HEIGHT | 11 |
| WIDTH BETWEEN FEET | 16 |
| LENGTH BETWEEN FEET | 16 |
