100 HP, 1150/1800 RPM, 240V, GENERAL ELECTRIC, CD505, SPECIAL COMPOUND USED DC MOTOR
 "10331800000 100 HP, 1150/1800 RPM, 240V, GENERAL ELECTRIC, CD505, SPECIAL COMPOUND USED DC MOTOR")
| INVENTORY ID | 10331800000 |
| TITLE | 100 HP, 1150/1800 RPM, 240V, GENERAL ELECTRIC, CD505, SPECIAL COMPOUND USED DC MOTOR |
| HORSEPOWER | 100 HP |
| SPEED | 1150 RPM |
| SPEED 2 | 1800 RPM |
| VOLTAGE | 240 VOLT |
| MANUFACTURER | GENERAL ELECTRIC |
| FRAME | 505 |
| WINDING | SPECIALCOMPOUND |
| ENCLOSURE | SV |
| SHAFT | SESS |
| AMPERAGE | 337 |
| DUTY | CONTINUOUS |
| BEARINGS | A/F |
| FIELD AMPERAGE | 3.65/1.65 |
| FIELD RESISTANCE | 34 |
| DEGREE OF TEMPERATURE RISE | 60 |
| SERIAL NUMBER OR ID NUMBER | XY1-1098 |
| MODEL NUMBER OR STYLE NUMBER | 5CD505F231 |
| DRIVE SHAFT DIMENSION | 2 7/8 |
| DRIVE SHAFT LENGTH | 7 |
